24 core ADSS cable, 24 core ADSS cable price

We know that the complete specifications of ADSS cable are: fiber core number, fiber type, span tension, jacket type. First of all, you asked me how much is the price of 24-core ADSS optical cable. I don't know how to answer, because I don't know how much span you need. The span of ADSS optical cable is determined by the tension of this project and the distance between the two rods.

This parameter is needed to determine, followed by it is not clear what ADSS cable sheath, ADSS cable sheath there are two kinds: PE sheath and AT sheath, PE sheath is voltage 110KV below the environment, AT sheath is voltage 110KV above the environment. As for the type of fiber, the ADSS fiber is basically single-mode, because single-mode fiber transmission distance.

The above parameters are clear after the manufacturer can quote according to the overall parameters and specifications, calculate the price of 24 core ADSS cable. The structure of 24 - core ADSS cable is lamellar structure. It is an all-dielectric nonmetallic power cable. The center strengthening part is FRP, if it is 24 core ADSS cable, the structure is 5+1, which can be 2 loose sleeve (1 loose sleeve has 12 optical fibers: blue, orange, green, brown, gray, white, red, black, yellow, purple, powder, green) +3 filling rope +1 non-metallic FRP center strengthening part.

Of course, according to the needs of customers, for example, for the convenience of the construction site, it is also possible to put 6 optical fibers in 1 loose casing, if that is, 4 loose casing (a loose casing has 6 optical fibers) +1 filler rope +1 non-metallic FRP center strengthening parts. The filling rope is used to round out the cable. ADSS fiber cable span tension, material aramid yarn plays a decisive role.
